Turbine Igniter & Control Leads
We sell afermarket turbine leads for GE, Pratt & Whitney, Westinghouse, Allison, etc Ground Applications. IV TECH GA, LLC is an authorized distributor for BG Service Company. Below is a partial list of the items we can help you obtain. Please contact us if you would like us to contact any manufacturer or if you do not see the items you are looking for on this site.
Ground Application
- All ARP670 type "M" terminals available.
- Type "F" terminals can be custom designed upon request.
- Brazed or swaged conduit construction.
- 100 psi pressure testing available for brazed conduits.
- Electric contacts available in standard spring type or exotic materials (tungsten, beryllium-copper, etc.).
- Standard insulation materials are alumina ceramic and premium electrical grade Teflon®.
- Spare part kits for BG turbine leads.
Electric Feedthroughs
The Electric Feedthroughs that we obtain through BG Products provide a leakproof electrical connection through the walls of a variety of pressure vessels. They are compatible with currently used refrigerants and phenolic oils. They have a superior leakage resistance, tested with a helium leak tester, and a standard acceptance leak rate of less then 1x10-6 cc/sec (He). Typical operating pressures are from ambient to 500 PSIG. They have a greater temperature capability than similar products, up to 250° F in operation service. Built with copper conductors and brass nuts for maximum electrical current carrying ability and lowest connection losses. They are available in a variety of sizes for most applications.
BG Electric Feedthroughs are used as terminals and overloads in...
- Semi-Hermetic Air Conditioning Compressors
- Semi-Hermetic Refrigeration Compressors
- Explosion Proof Electric Motors
- Electromagnets
- Vacuum Furnaces
- Electric Steam Generators
- Autoclaves
- Oil & Gas Filled Transformers and Switching Equipment
- Centrifugal and Submersible Pumps
